Round-stock centre marking guide — CentreV | JLF-313

COLOR: BLACK. The supplied print is black; render colors are illustrative. Find a round end's centre using an orthogonal fence and diagonal guide. DIMENSIONS 120 mm frame with two perpendicular locating faces and 1.2 mm bisector slot. CONTENTS 1 printed pieces: 1 × round stock centre marker. Material: PLA. SUPPLY SEPARATELY Round stock, fine pencil and caliper for checking printed squareness. USE AND ASSEMBLY Rest the circular end against both fence faces, draw along slot, rotate stock and repeat. Intersection estimates the centre. Pencil marking only, not a drill fixture. Images are renders of the actual CAD. Geometry and reference slicing checked digitally; physical fit, finish and service life have not been established by those checks. Printed to order. Shipping and taxes are calculated at checkout. Design: João Lutz / JoaoLutzFilm, with AI assistance.
